Android plan |
CPU | Rockchip RK3568Cortex-A55, quad-core 64-bit |
GPU | ARM G52 2EE |
Main frequency | 2.0 GHz |
memory | DDR 2G |
Built-in memory | EMMC 16G |
Operating system | Android 11.0 |
USB2.0 interface | USB2.0*1、USB3.0*1 |
LVDS output | 1 pc, which can directly drive the 50/60Hz LCD screen |
HDMI output | 1 pc, support 1080P export |
Network support | Equipped with RJ45 interface, wired/WIFI (2.4G, optional 5G). |
Image rotation | Support 0 degree, 90 degree, 180 degree, 270 degree manual/automatic rotation |
Android version feature description | |
Network support | Ethernet, support WiFi, wireless peripheral expansion, Bluetooth 4.0 |
Play content | Images, videos, PDFs, text, web pages, live feeds, local resources |
Multiple controls | Local weather restrictions, calendar, bank exchange rates, timing, countdown |
Cloud platform information release | Install the software, log in to the cloud platform anytime and anywhere to remotely control any networked advertising equipment, and centrally manage it across regions |
Layout templates | A variety of split screens are freely matched, the layout templates are rich, and the mixed split screen realizes the trouble of a single split screen, making the advertising display more exciting |
Interactive templates | There are static and dynamic online template downloads, which removes the trouble of making promotional advertisements and makes the advertisements dazzling |
Mobile phone cloud control APP | Mobile phone fast transmission, quick control and monitoring |
Automatic updates | The new features of the cloud platform are launched, and your account is synchronized instantly, so you don't need to update and upgrade yourself, and you can synchronize our new features at any time |
Display mode | Controllable full-screen, split-screen playback (make multi-screen display, logo area, perpetual calendar area, video area, picture area, Subtitle area, etc.) are divided at will, and the screen display is arranged by itself |
Boot up | Automatically loop when you turn on the power |
Breakpoint memory | Supports breakpoint memory function |
Regularly turn the power on and off | Support timed power on and off function, unattended around the clock |
It can also be used as a stand-alone machine | When the network is disconnected, it can be used as a stand-alone version, and it can still produce diversified content through powerful background information publishing software and then export it Copy it to the memory card and insert it into the advertising machine to loop it |
Language menu | Support Chinese, English and other Chinese languages |
Smart remote control | Full-function remote control operation |
Security and anti-theft | It has an anti-theft lock function to prevent theft of machines or storage |
Playback media | USB flash drive, SD card |
Playback settings | Loop, random, unicast, sequential |
Image playback | Rotate, zoom, pan, slideshow play, and other toggle effects |
Anti-theft lock | Prevent machine or storage device theft |
