Panel brand

Huaxing (A-gauge screen)

Product color

Silver, black, customizable color (white, green, red, etc.)

Product Type:

Infrared Touch Advertising Machine (Android System)

Display type

LED LCD display

Physical resolution

3840*2160

Show color

10bit, 1.07B

Refresh rate

4K-60Hz as standard

Brightness

Up to 350 cd/m2

Contrast

5000：1

Viewing Angle (Degrees)

178°

Backlight life

50,000 hours

Touch embedding

Built-in one-piece, not external

Touch-sensing technology

Infrared Sensing Recognition Touch Technology (10 points)

Writing style

Fingers, styluses, or other non-transparent objects with a diameter of at least 5mm (multi-point 8mm)

Cursor speed

120 pips/s

Positioning accuracy

More than 90% of the touch area is ±2mm

Communication interface

Type B USB male

Touch interface

Tempered glass

Number of touches

Theories are infinite

Computer response

automatic recognition by the system; ≤8ms

Drivers

HID is exempt from driving

Touch function

Support 10-point computer touch operation

Support image enlargement, reduction, and rotation

Shell and appearance

The fuselage is made of metal sprayed metal cold-rolled steel plate, and the surface is 3.5mm tempered glass.

Color

Standard black (silver, white optional)

Operating voltage

AC110-220V

Maximum power consumption rate

≤430W

Standby power

≤2.5W

Installation method:

TV wall mount (optional mobile stand) as standard

Speaker specifications

10W / 8 ohm × 2 speakers

Environmental parameters

workplace

Indoors

Operating temperature

0°C - 40°C

Operating humidity

10% - 90% non-condensing

Storage temperature

-20°C - 60°C

Storage humidity

10% - 90% non-condensing

Zhuo Ce 3568

Motherboard (2+16) 4K

configuration

CPU

Rockchip RK3568 Cortex-A55, quad-core 64-bit

GPU

ARM G52 2EE

Main frequency

2.0 GHz

memory

DDR 2G

Built-in memory

EMMC 16G

Operating system

Android 11.0

USB2.0 interface

USB2.0*1、USB3.0*1

LVDS output

1 pc, which can directly drive the 50/60Hz LCD screen

HDMI output

1 pc, supports 2160P output

Network support

With RJ45 interface, wired/WIFI (2.4G, optional 5G)

Image rotation

Support 0 degree, 90 degree, 180 degree, 270 degree manual/automatic rotation
