Panel brand

Huaxing, BOE

Product color

Silver, black, white, can be customized color

Product Type:

Capacitive Touch Advertising Machine (Windows System)

Display type

LED LCD display

Physical resolution

1920*1080 standard (3840*2160 4K optional).

Show color

10bit, 1.07B

Refresh rate

2K-60HZ (4K-60HZ Optional)

Brightness

Up to 350 cd/m2

Contrast

5000：1

Viewing Angle (Degrees)

178°

Backlight life

50,000 hours

Touch mode

Capacitance G+F

Touch-sensing technology

Capacitive Sensing Recognition Touch Technology (10 points).

Writing style

Fingers, styluses, or other non-transparent objects with a diameter of at least 5mm (multi-point 8mm)

Touch calibration

Software

Positioning accuracy

More than 90% of the touch area is ±2mm

Communication interface

Type B USB male

Touch interface

Tempered glass

Number of touches

Theories are infinite

Computer response

automatic recognition by the system; ≤8ms

Drivers

HID is exempt from driving

Touch function

Support 10-point computer touch operation

Support image enlargement, reduction, and rotation

Shell and appearance

The fuselage is made of metal sprayed metal cold-rolled steel plate, and the surface is 3.5mm tempered glass.

Color

Standard black (silver, white optional)

Operating voltage

AC110-220V

Maximum power consumption rate

≤90W

Standby power

≤2.5W

Installation method:

Vertical mount (with base)

Speaker specifications

10W /8Ω×2 speakers

Environmental parameters

workplace

Indoors

Operating temperature

0°C - 40°C

Operating humidity

10% - 90% non-condensing

Storage temperature

-20°C - 60°C

Storage humidity

10% - 90% non-condensing

CPU

INTEL i5 4th generation (optional)

GPU

ARM Mali TM-450

Main frequency

1.8 GHz

memory

DDR3 4G (optional)

Built-in memory

SSD 128G (optional)

Operating system

WIN10 Activation Edition (WIN7 Optional)

USB2.0 interface

USB2.0*4（3.0）

LVDS output

1 pc, which can directly drive the 50/60Hz LCD screen

HDMI output

1 pc, support 1080P output

Network support

It has RJ45 interface, WiFi-2.4G (optional BT4.2) 100M/10M adaptive Ethernet

Headphone port

3.5mm headphone jack
